1000319
Self-aligning Polymagnet
This magnet pairs with itself. This is the grade N40 version of the N50 Polymagnet 1001048 .
This Polymagnet provides a self-alignment function as well as shear resistance along its long axis in magnet-to-magnet applications
More Information
SKU: 1000319
Meta Description: 1000319
Part number: 1000319
Pairs with: 1000319
Availability date: Released
Base Polarity: South
Magnetization orientation: Through Thickness
Coating: Ni-Cu-Ni
Material: NdFeB
Grade: N40
Temperature Rating (C): 80
Temperature Grade: Standard
Shape type: Rectangle
Length (inch): 2
Width (inch): 0.25
Thickness (inch): 0.062
Mass (oz): 0.1295
Length (mm): 50.8
Width (mm): 6.35
Thickness (mm): 1.587
Mass (g): 3.67
Countersink: 0
Magnet Family: Align
Length fractional(inch): '2"
Alignment Functionality: One Dimensional Alignment
Shear resistance: One Dimensional Shear
Latch Functionality: 0
Spring Functionality: 0
Torque Functionality: 0
Magnet Symmetry: 0
magnet_plate_length_range: 50.8
Indexing Feature: 0
