1002256
Attach Polymagnet - long range - centering
This magnet pairs with itself and the following:
This Polymagnet provides a high holding force in magnet-to-magnet and magnet-to-steel applications, at design gaps greater than 0.75 mm. It also provides radial shear resistance in magnet-to-magnet applications.
More Information
SKU 1002256
Meta Description 1002256
Part number 1002256
Pairs with 1002256
Availability date Released
Base Polarity South
Magnetization orientation Through Thickness
Coating Ni-Cu-Ni
Material NdFeB
Grade N50
Temperature Rating (C) 60
Temperature Grade Standard
Shape type Disc
Thickness (inch) 0.125
Outer diameter (inch) 0.625
Mass (oz) 0.1658
Thickness (mm) 3.175
Outer diameter (mm) 15.875
Mass (g) 4.7
Countersink 0
Magnet Family Attach
Alignment Functionality Radial Alignment
Shear resistance Radial Shear Resistance
Latch Functionality 0
Spring Functionality 0
Torque Functionality 0
Magnet Symmetry Radial
magnet_disc_od_range 15.875
magnet_disc_length_range 1
Indexing Feature 0
