1002275
Torque Polymagnet - twist release - 45 degree
This magnet must be paired with the following:
This Polymagnet has been removed from the from the catalog in favor of 1002232 with a different countersink size; 1002275 can still be ordered in volumes >100 and with a 6 week lead time by emailing orders@polymagnet.com
This torque Polymagnet features rotational alignment and torque resistance. The pair of 1002274 and 1002275 exhibits a high attract force when rotationally aligned, and a high repel force when rotated 45 degrees in either direction, forming a twist-release mechanism.
More Information
SKU 1002275
Meta Description 1002275
Part number 1002275
Pairs with 1002274
Availability date Released
Base Polarity South
Magnetization orientation Through Thickness
Coating Ni-Cu-Ni
Material NdFeB
Grade N50
Temperature Rating (C) 60
Temperature Grade Standard
Shape type D-shape
Length (inch) 1
Thickness (inch) 0.125
Outer diameter (inch) 1
Mass (oz) 0.3986
Length (mm) 25.4
Thickness (mm) 3.175
Outer diameter (mm) 25.4
Mass (g) 11.3
Countersink #6
Magnet Family Torque
Length fractional (inch) 1"
Alignment Functionality Rotational Alignment
Shear resistance Rotational Shear Resistance
Latch Functionality 0
Spring Functionality 0
Torque Functionality 0
Magnet Symmetry 0
magnet_dshape_length_range 1
Indexing Feature D-shape
